Description

Features

• Dual Channel Mixer
• User-Friendly Control Center
• LCD Status Window
• Auto-Save Function
• 9-Steps Music Key Control
• Microphone Master Volume and Music Master Volume
• Independent Microphone Volume Control
• Microphone Delay/Repeat/Echo/Bass/Treble Control
• Music Bass/Treble Control
• Headphone Jack with Volume Control
• (4) ¼” Microphone Inputs
• (4) RCA Audio Inputs
• (1) Optical Input
• (1) Coaxial Input
• (2) RCA Audio Outputs
• Voltage Selector

Tech Specs

• Source Input: DVD, AUX 1, AUX 2, AUX 3, Optical, Coaxial
• Microphone Input: 4 (Front x 2, Rear x 2)
• Audio Inputs: 4 (RCA jacks)
• Audio Outputs: 2 (RCA jacks)
• Dynamic Range: 2V@20~20kHz
• Mic Sensitivity: 8mVrms
• Operating Humidity Range: 90%
• Operation Temperature: -5 ~ 45 °C
• Frequency Response: 20Hz~20kHz 0.5dB/-3dB
• Max Distortion: 0.1%
• S/N RATIO (Music): >90dB
• Power Consumption: 10W
• Power Requirement: ~110V 60Hz / ~220V 50Hz
• Dimensions (WxHxD): 17.4×2.8×10 in / 44.2x7x25.3 cm
• Packing Dimensions (WxHxD): 20.3×5.4×12.8 in / 51.5×13.7×32.5 cm
• Net Weight: 7.7 Lbs / 3.5 Kg
• Shipping Weight: 8.8 Lbs / 4 Kg
• UPC Code: 743062981473

Specifications

• Weight: 200gr
• Usage: Indoor & outdoor

Pros and cons

• Sustainably produced
• Ideal for everyday use
• May discolor in direct sunlight
