Features:
Frequency response
40HZ-18KHZ(±2db)
Rated Power
3MW-30MW
Application
Karaoke,Outdoor,Stage,Singing,Speaking,Shows
Special Feature
Portable, Wireless, Durable
Powered by
2 AA 1.5V alkaline batteries
Keyword
wireless microphone system
Use
Singing
FEATURES
Six-axis gyroscope sensor integrated onto each microphone.
Intelligent Energy Control.
Automatic Gain Control (AGC) Technology prevent microphone feedback.
UHF Dual-Channel in a 2-in-1 Base Module.
Utilizing the latest wireless technologies and engineering.
Clear Voice Technology delivers crystal clear sound.
Wireless Auto Sync System technology makes setting up a breeze.
High Definition LCD Screen displays Radio Frequency Level, Audio Frequency Level, Channel, Frequency, Battery, Volume, Mute and Lock.
100 selectable channels for each microphone.
Manual Frequency Select and Automatic Frequencies Scan.
Auto-Mute Mode and Auto-Shutdown activates when microphone is left unattended.
AA batteries for easy usage and up to 8 hours of battery life.
TECH SPECS
A. TECHNICAL FEATURE OF THE SYSTEM
Channel: 100 Channels
Frequency Range: UHF 926~936 MHz
Frequency Response: 50Hz~18kHz
Effective Use Range: ≈30m
Frequency Spacing: 1MHz
Band Width: 50MHz
Package Dimensions (WxHxD): 18.9×2.8×13.4 in / 48x7x34 cm
Shipping Weight: 6.1 lbs / 2.8 kg
B. TECHNICAL FEATURE OF THE 2-IN-1 BASE MODULE (Receiver)
Signal to Noise Ratio: ≥50dB
Audio Output: 1 x Unbalanced TRS 6.3mm Socket
Signal Pick Up: CPU controlled selection & pilot identification
Mute: Mute & lock loop circuit
Display: LCD
Power Supply: DC 12V with 1.25A, Input: AC 120V (For 220V, you may need to change to a 220V~240V DC adaptor)
Receiver Dimensions (WxHxD): 16.5×1.7×5.5 in / 42×4.3×14 cm
Net Weight: 2.8 lbs / 1.3 kg
C. TECHNICAL FEATURE OF THE MICROPHONE
Transmitter Power: Low (5mW), High (10mW)
Frequency Spacing: 1MHz
Band Width: 50MHz
Display: LCD
Capsule: Dynamic
Battery Life: 8 Hours
Battery Voltage: 2 x AA 1.5V Alkaline Battery
Microphone Height & Circumference: 9.8 & 2 in / 24.8 & 5.1 cm
UPC Code: 743062981466
FEATURES
Smart Sensor integrated onto microphones.
Auto-Mute Mode activates upon impact.
Energy-efficient Sleep Mode.
Equipped with the latest wireless technology UHF dual-channel 2-in-1 Base Module.
Clear LCD screen displaying Radio Frequency Level, Audio Frequency Level, Frequency, Channel, Mute, and Lock.
Wireless Infrared Auto Sync System.
Manual and Auto Frequency Select.
100 selectable channels.
Clear Voice technology delivers crystal clear sound.
Adjustable antennas for better signal receiving.
AA battery usage for easy handling.
Up to 8 hours of battery life.
Rack mountable.
TECH SPECS
2-IN-1 BASE MODULE & HANDHELD MICROPHONE:
Channel: 200 Channels
Frequency Range: UHF 480.100~529.850 MHz
Modulation Method: /4 -DQPSK
Sampling Ratio: 48kHz
Transmission Rate: 204.8Kbps
Dynamic Range: > 90dB
Total Harmonic Distortion: < 0.1%
Delay Time of Audio Transmission: <3ms
S/N Ratio: >96dB
Frequency Response: 30~20kHz
RX Sensitivity: < –94dBm
Unique ID Address: YES
Audio Output: 2 x XLR Port
Power Supply: DC 12V~18V with 500mA, AC 120V (For 220V, change to a 220V~240V DC power adaptor)
Receiver Dimensions (WxHxD): 8.7 x 2 x 7.1 (inches) / 22 x 5 x 18 (cm)
Package Dimensions (WxHxD): 15.6 x 12.2 x 2.7 (inches) / 39.5 x 31 x 6.8 (cm)
Shipping Weight: 4.6 lbs / 2.1 kg
UPC Code: 743062981275
FEATURES
Six-axis gyroscope sensor integrated onto each microphone.
Energy efficient microphones.
High Tech Auto-Mute function activates when falling motion is detected.
Sleep mode activates when microphone is left unattended.
Equipped with the latest wireless technology and UHF dual-channel in a 2-in-1 Base.
Clear LCD screen displays Radio Frequency, Volume, Channel, and Frequency.
Wireless Auto Sync System technology makes setting up a breeze.
Clear Voice technology delivers crystal clearer sound just like a wired microphone.
100 selectable channels for each microphone!
Adjustable antennas for better signal receiving.
AA batteries for easy usage.
Receiver Left / Right squelch knobs.
TECH SPECS
A. 2-IN-1 BASE MODULE
Channel: 100 Channels (total 200 Channels)
Frequency Range: UHF 602~652 MHz
Signal to Noise Ratio: > 90dB
Total Harmonic Distortion: < 0.5%
Band Width: < 250kHz
Frequency Response: 30Hz~19kHz +/-3dB
Sensitivity: ＞100dB
Effective Use Range: ＞50M
Receiver Shell: EIA standard 1/2U
Receiving Sensitivity: 2.0μV
Audio Output Level: Unbalanced Out: 0~+/-400mV; Balanced Out: 0~+/-200mV
Power Supply: DC 14V~22V with 500mA~1000mA, AC 120V (For 220V, you may need to change to a 220V~240V DC adaptor)
Consume Power: 5 Watts
Receiver Dimensions (WxHxD): 8.2 x 1.7 x 6 in /20.9 x 4.2 x 15.2 cm
Package Dimensions (WxHxD): 16.9 x 13.7 x 2.8 in /42.8 x 34.7 x 7.2 cm
Shipping Weight: 5.6 Lbs / 2.5 Kg
B. HANDHELD MICROPHONE
Transmitter Power: 5mW or 10mW (Switchable)
Osillation Mode: PLL
Harmonic Radiation: ≤-50dBc
Frequency Stability: ±0.005%，at 0～50℃
Battery Voltage: 2 x AA 1.5V Alkaline Battery
Continuous Using: 8 Hours (GP) 2 x AA 1.5V Battery
Power: DC 2.4~4.8V
Microphone Dimensions (WxH): 10.3 x 2.2 (inches) / 26.2 x 5.7 (cm)
UPC Code: 743062980933
